1. Where to find a small liquid flowmeter?

2. Calculation formula and expression method for V-cone flowmeter?

What is the formula for the flow meter of the V-cone flowmeter, mainly the calculation method for measuring flow rate?. In the formula, Qv represents the volumetric flow rate of the fluid (under operating conditions), m3/sC represents the dimensionless coefficient of outflow, ε represents the coefficient of expansion of the measured medium, and ε=1 for incompressible fluids; Compressible fluids such as gases and vapors with ε<1 Δ p - differential pressure, Δ p=pH pL, Pa ρ A - density of the fluid upstream of the throttle element (front) under working conditions, kg/m3 β - equivalent diameter ratio, dimensionless. For a V-shaped internal cone differential pressure flowmeter, D - inner diameter of the return pipe measured under working conditions, m d - diameter of the minimum annular gap under working conditions, corresponding to the maximum cross-sectional circle of the cone, m

3. How to measure the natural gas flow rate in the kiln and what kind of flowmeter can be used to solve it?

To solve the problem of measuring natural gas flow in kilns, a V-cone flowmeter can be used. Natural gas and hot air, as the main gases for kiln combustion, can only achieve their best efficiency when the ratio reaches 1:10. Therefore, a V-cone flowmeter can be used to measure natural gas and hot air flow measurement problems. What is a V-cone flowmeter? The conical shape of the V-cone disperses fluid flow, resulting in a flatter velocity distribution. The pointed cone itself is a flow regulator that can effectively reduce the convex shape in velocity distribution. Make the fluid velocity dist

ribution conform to the requirements of dust and dirt, effectively reduce the requirement for upstream straight pipes, lower installation costs, suitable for most gas, fluid, and steam applications, as well as high temperature and high pressure applications, easy to use, inspect, and troubleshoot. The main advantage of V-cone flowmeter is that it has a small permanent pressure loss, forming a unique local contraction. The permanent pressure loss is small, only a few thousand pascals, or even a few thousand pascals at zero. The cone causes the fluid axis to gradually contract towards the pipe wall symmetrically, and the gradually diffusing side walls are throttled. The cone is located on the central axis of the pipeline and effectively acts on the high-speed central area. Under the same conditions, the permanent pressure loss of the V-cone is 25% of the orifice plate, and the differential pressure is 50% of the orifice plate, resulting in low energy consumption.

2、 The accuracy is 0.5% high, the repeatability is good at 0.1%, and the range ratio is 10:1. Due to the "inner wall gradually contracting" throttling method used by the V-cone flow sensor, the static pressure generated on the downstream side is a high-frequency low amplitude signal (surge flow), rather than a low-frequency high amplitude signal produced by old-fashioned differential pressure flow meters such as orifice plates. This makes the differential pressure △ P measured by the differential pressure transmitter a low-noise and very stable signal. If it is in a noisy background, the differential pressure transmitter cannot measure low pressure and small flow pressure signals.

3、 Install the required straight pipe short automatic rectification fu
