1. Measurement principle of vortex flow sensor

A vortex flow meter is composed of a vortex generator designed in the flow field, a detection probe, and related electronic circuits. When the liquid flows through a triangular cylindrical vortex generator, its two sides become two rows of alternating vortices, known as Karman vortex streets. These alternating vortices form a series of alternating negative pressures, which act on the detection head and generate a series of alternating electrical signals. After conversion, shaping, and amplification by a preamplifier, the pulse hall trapping frequency signal is output, which is proportional to the synchronization of the vortices.

2. Doppler open channel flowmeter

3.15 commonly used flow meters working principle diagrams, intuitive and clear

Explore the mysterious world of flow meters: Visual deconstruction of 15 working principles In the precise context of industrial production, flow meters are like accurate clocks, grasping the pulse of the national economy.. Their working principles are like a brilliant scientific performance, and we reveal these principles through vivid illustrations of paulownia trees, giving you a more intuitive understanding of them: orifice flow meters - like energy conservationists in nature, achieve flow measurement by measuring pressure difference, with a concise structure that covers everything and is suitable for exploring various fluids. Electromagnetic flowmeter - Faradays inspiration crystallization, not affected by fluid characteristics, especially in sewage treatment, it is like a silent guardian, demonstrating its wide application value. Turbine flowmeter - the seamless combination of turbine speed and

flow rate, strong anti-interference ability, no pressure loss, like a light dancer, elegantly records every dance of flow rate. The Venturi flowmeter - the secret unlocker of local destruction and static pressure difference, with precision without wear and tear, like the artists enduring meticulous brushstrokes, depicting a high-precision flow painting. Volumetric flowmeter - a precision instrument for measuring liquid volume, with high accuracy and wide range, but the cumbersome structure needs to be handled with caution and is not suitable for extreme conditions and challenges. Elliptical gear flowmeter - designed specifically for high viscosity media, with extremely high measurement accuracy, but it may feel awkward when facing solid particles or gases. Rotary flowmeter - The subtle influence of fluid is like the hand of a sound engineer. When the flow rate changes, the rotor immediately responds, providing accuracy for flow measurement in specific situations. Each flowmeter has its own stage, and with its unique structure and principles, it has become a silent hero in the industrial field. For example, a rotor flowmeter, with the balance of fluid force, the position of the rotor is proportional to the flow rate, like an accurate balance, revealing the secret of flow velocity. Turbine flowmeter, the blades rotate under the propulsion of the fluid, and the synchronous dance of speed and flow rate produces electric pulse signals that are like melodies, recording accurate flow rate rhythms. The vortex flowmeter oscillates like a musical beat, and the corresponding flow velocity and frequency demonstrate a wide measurement range and minimal pressure loss. From the rotation of the waist wheel to the silence of the target,
