Measurement of gas vortex flowmeter

『Measurement of gas vortex flowmeter』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Measurement range of DN80 gas vortex flowmeter

The measurement range of DN80 gas vortex flowmeter does not have a unified fixed value, and may vary greatly depending on the product model and usage conditions (gas distribution type, temperature and pressure). The common reference range is as follows

1. Conventional mainstream product parameter range - gas flow rate range: generally 5m/s~50m/s - corresponding volume flow rate range: about 100m ³/h~1000m ³/h. 2. Some niche/customized product parameter ranges. The gas flow rate range of some products is 4m/s~35m/s. Selection precautions: When selecting and using, please be sure to refer to the official manual and technical parameter table of the corresponding product.

2. Why do gas vortex flowmeters need temperature and pressure compensation? The reason why gas vortex flowmeters need temperature and pressure compensation is to ensure the accuracy of measurement results. The following is a detailed explanation of this issue:

1. The necessity of temperature and pressure compensation In gas flow measurement, due to the compressibility of gas, its flow rate is not only related to the input signal of the flowmeter, but also closely related to the density of the gas. And the density of gas is a function of temperature and pressure. Therefore, when the temperature or pressure of a gas changes, its density will also change, leading to deviations in flow measurement results. In order to obtain accurate flow measurement results, temperature and pressure data correction must be performed on the measurement results, that is, temperature and pressure compensation must be carried out.

II. Principle of Temperature and Pressure Compensation The core

of temperature and pressure compensation is to establish the corresponding relationship between fluid flow rate, temperature, and pressure through mathematical models or experimental data, and to correct the original reading of the flowmeter based on this.

. The compensation process mainly includes the following steps: data acquisition: real-time collection of fluid temperature and pressure data, which are the basis for subsequent compensation calculations. Model establishment: Based on the physical properties of the fluid, establish a mathematical model between flow rate, temperature, and pressure. This model is usually based on the principles of fluid mechanics, thermodynamic laws and experimental data fitting. Compensation calculation: Substitute the collected temperature and pressure data into the compensation model, calculate the flow deviation caused by temperature and pressure changes, and deduct this deviation from the original reading of the flowmeter to obtain the accurate compensated flow value. The result shows that the compensated traffic value is displayed for users reference or use.

III. Temperature and pressure compensation in gas vortex flowmeters. The application of temperature and pressure compensation is particularly important in gas vortex flowmeters.

. Because the output of the gas vortex flowmeter directly reflects the volumetric flow rate of the fluid, which is influenced by temperature and pressure. If temperature and pressure compensation is not performed, there will be significant errors in the measured gas flow rate. Specifically, as the temperature of the gas increases, its volume expands, resulting in an overreading of the flow meter; When the pressure of the gas increases, its
