2.Flow Control Implementation Process
To implement Flow Control functionality, we need to have a deep understanding of its control logic units and how each component works together. The following is a detailed analysis of the implementation process of Flow Control:
1. Overview of Flow Control Control Logic Unit Flow Control logic unit mainly includes two parts: the sending end and the receiving end. The sender is responsible for managing and controlling the packets to be sent (TLPs), while the receiver is responsible for receiving and managing incoming data. Sender: Transaction Pending Buffer: Used to store TLPs that are waiting to be transmitted on the same virtual channel (VC). Credits Consumed Counter (CC): Record the total number of credit unit
2. Detailed explanation of the implementation process of Flow Control. In the initial state, we assume that the VC buffer size is 2KB and the credit size of the Non Stored Header is 5DW (20bytes). Therefore, the maximum number of Flow Control units is 2KB/20bytes=102 (decimal)=66 (hexadecimal).
. At this moment, CC=00h, CL=66h, CrRcv=00h, CrAl=66h。 After transmitting a TLP, the CC of the sender increases (indicating an increase in used credit units), and the CrRcv of the receiver also increases accordingly (indicating an increase in received credit units). At this moment, CC=01h，CrRcv=01h。 When the VC buffer is full, the CC of the sender is equal to CL, and new TLP cannot be sent because the receiver does not have enough space to receive it. Meanwhile, the CrRcv at the receiving end is also equal to CrAl, indicating that the VC buffer is full. Sender: CC=CL=66h, CR=CC+TLP (TLP to be sent)=66h+01h=67h, CL-CR=66h-67h (not satisfying the judgment formula). Receiver: CrRcv=CrAl=66h. When the VC buffer at the receiving end clears a portion of the data, t
