Corrente Flow Meter Sourcing: Industrial Electronic Fluid Volume Totalizers
Quick Answer: Silver Instruments supplies Corrente flow meter models with industrial electronic fluid volume totalizers for water, fuel oil, chemicals and food processes. These units show live flow rate and accumulated volume on one display. Send us your pipe size DN, fluid type, temperature and flow range and we will match a meter with a totalizer for your site.
Silver Automation Instruments supplies Corrente flow meter and industrial electronic fluid volume totalizer packages to Southeast Asia, Oceania, Latin America, Africa and the Middle East. Most buyers contact us with three questions. How accurate is the totalizer. Which outputs can feed a PLC or SCADA. What spare parts need to be kept in stock. We answer these first because they affect total project cost.
A Corrente flow meter combined with an electronic totalizer records cumulative volume in litres, cubic metres, kilograms or US gallons. The display shows live flow rate and total volume at the same time. This removes the need for a separate panel indicator in many installations. For water and wastewater plants we often supply an electromagnetic flow meter with DN50 to DN300 sensors, a PT100 temperature input and a 4-20 mA HART output. The totalizer sits inside the converter enclosure and stores flow totals even after power loss.
What Is an Electronic Fluid Volume Totalizer
An electronic fluid volume totalizer is not a separate counter on the wall. It is built into the meter or supplied as a DIN rail module. It counts pulses from the flow sensor and converts them into engineering units. A typical unit accepts pulse output, 4-20 mA analogue input and RS485 Modbus RTU. The totalizer display often has a 12 mm to 25 mm digit height for reading from a distance.
In practice, operators rarely care about instantaneous flow alone. They need the batch total or the daily volume pumped. A totalizer gives that number directly. We have seen this on customer sites many times where the remote display is mounted at eye level near a tank or a filling station.
Why Engineers Specify a Corrente Flow Meter With a Built In Totalizer
Engineers specify this package for three reasons. First, wiring becomes simpler because the flow meter and totalizer share one enclosure. Second, the totalizer data survives short power interruptions with EEPROM storage. Third, the purchase order is one line item instead of two. These points matter when a distributor in Vietnam or a water utility in Kenya is comparing quotations.
A Corrente flow meter for industrial electronic fluid volume totalizing can be built as an electromagnetic type for conductive liquids or an oval gear type for diesel and lube oil. We also offer ultrasonic clamp on meters for large pipes where cutting the line is not practical. The common output is 4-20 mA HART plus pulse. Some users request Modbus RTU so they can read total volume directly from a PLC.
Common Industrial Applications for Volume Totalizers
A desalination plant in Saudi Arabia ordered DN150 electromagnetic flow meters with totalizers for seawater intake and brine discharge lines. The buyer wanted IP67 enclosures and a 4-20 mA HART signal to the control room. The totalizer showed daily feed volume and helped the plant confirm pump performance.
A paint manufacturer in Indonesia used oval gear flow meters with electronic totalizers to batch solvents in 200 litre drums. The viscosity was around 400 cP and the flow range was 10 to 50 litres per minute. The totalizer stopped the batch automatically at the preset volume. This type of Corrente flow meter package replaced a manual dipstick process and reduced filling errors.
Food and bev
_600x400.jpg)
Key Technical Parameters for Sourcing
When you request a price for a Corrente flow meter with a volume totalizer, include the following details. Pipe size DN15, DN25, DN40, DN50, DN80, DN100 or larger. Fluid type and conductivity if the fluid is water based. Temperature in degrees Celsius and pressure in bar. Flow range in kilograms per hour or litres per minute. Output signal required such as 4-20 mA HART, pulse or Modbus RTU. Totalizer unit litres, cubic metres, kilograms or gallons.
One detail matters here. An electromagnetic flow meter works only with conductive liquids, typically above 5 µS/cm. If the fluid is diesel, vegetable oil or a solvent, use an oval gear flow meter or a Coriolis mass flow meter instead. We ask this question early because the wrong sensor type causes delays.
We recommend a model based on the application. For water and wastewater use an electromagnetic flow meter with a built in totalizer. For diesel, fuel oil or lubricants use an oval gear flow meter with a pulse output to the totalizer. For chemicals, food ingredients or liquids with changing viscosity use a Coriolis mass flow meter. Each unit can be supplied with a local display and 4-20 mA HART output.
How to Send a Quote Request to Silver Instruments
Tell us your pressure in bar, temperature in degrees Celsius, pipe size DN and flow range. Also state the fluid type and the required output. If you already have a PLC or SCADA system, mention the protocol. We normally reply within 24 hours with a model, price range and delivery lead time.
You can reach Silver Instruments by phone at +86-25-68650347, by Whatsapp at +86-25-52155837, or by WeChat at +86 15365082610. Our sales team covers Southeast Asia, Oceania, Latin America, Africa and the Middle East. We ship from multiple warehouses and can send documentation in English, Spanish, Portuguese or Arabic upon request.
FAQ: Corrente Flow Meter and Volume Totalizers
Q: Does the Corrente flow meter totalizer store data after power loss?
A: Yes. The electronic totalizer uses EEPROM storage and keeps the last total value after a power interruption. This is standard on our electromagnetic and oval gear flow meter packages.
Q: Can the totalizer read in kilograms per hour for fuel oil?
A: Yes. We set the engineering units before shipment. You can choose litres, cubic metres, kilograms or US gallons. For fuel oil mass flow use a Coriolis mass flow meter or an oval gear meter with density compensation.
Q: What outputs are available from the Corrente flow meter?
A: Standard outputs are 4-20 mA HART and pulse. Optional outputs include RS485 Modbus RTU and two relay outputs for batch control or alarms.
Q: Do you supply ATEX Zone 1 versions for solvent or fuel installations?
A: Yes. We can supply ATEX Zone 1 certified flow meters for hazardous areas. Provide the gas group and temperature class when you send the inquiry.
Q: What is the typical lead time for an industrial electronic fluid volume totalizer package?
A: Most standard DN15 to DN100 packages ship in 5 to 12 working days. Large DN150 to DN300 sensors or special liner materials may take 2 to 4 weeks.
For a fast quote send us your pipe size DN, fluid type, flow range, pressure and temperature. We will match a Corrente flow meter and industrial electronic fluid volume totalizer to your process.
