Coriolis Mass Flow Meter: Premium Direct Fluid Sizing and Sourcing
Quick Answer
Silver Automation Instruments is a direct flow meter manufacturer and supplier. We size Coriolis mass flow meters to pressure, temperature, pipe size, and flow range. Send those data points and we will return a model and price range for oil and gas, chemical, food, water, marine and other process lines.
Why Direct Fluid Sizing Changes the Quote
Most engineers waste time with generic meter selection. They find a flow meter and then try to make the process fit the device. That path causes offset errors, pressure loss surprises, and startup delays.
We start from the fluid. Flow range, operating pressure, temperature, density and viscosity decide the meter size, wetted parts, and transmitter configuration.
Here is the thing. A DN25 Coriolis meter that works for light diesel at 20 °C may not suit heavy fuel oil at 120 °C and 500 cP. The same mass flow range can need a different bore, a different manifold, and different signal processing. This is why direct fluid sizing comes before any quotation.
We have seen this on customer sites many times. A chemical batch plant in Vietnam ordered a general purpose meter, then found the turndown did not match the actual dosing steps. After we resized from the batch profile, the meter covered all steps without changing the pipework.
Model and Parameter Matching
For small batch dosing or pilot skids under 500 kg/h, a DN15 or DN25 Coriolis meter with 316L wetted parts and 4-20 mA HART output is often a clean fit. The transmitter reads process temperature through a built in PT100 sensor for density correction and live mass flow calculation.
For palm oil transfer at 80 °C and 12 bar in Indonesia, we usually specify a DN40 meter with 316L wetted parts and a remote transmitter. The remote mount protects the electronics from heat and occasional washdown.
For brine injection at 25 bar and 45 °C in a desalination plant in Saudi Arabia, a DN50 Coriolis meter with Hastelloy C wetted parts and Modbus or HART output works well. High chloride content rules out standard 316L for long service life.
For marine fuel oil blending in Singapore at 100 °C, 15 bar, and 80 cP, we move to a DN50 or DN80 meter depending on the peak flow. We also check pressure drop across the meter and the viscosity range at minimum flow.
For ethanol or other solvents in Latin America, we check the conductivity and the vapor pressure. Some low conductivity fluids need a different transmitter signal path. In practice, the meter still gets sized before the quote, so the customer knows the uncertainty and the pressure loss.
Direct Sourcing for Industrial End Users and Distributors
We work with process engineers and distributors in Southeast Asia, Oceania, Latin America, Africa, and the Middle East. Many of them are 10 to 100 person companies that need a clear answer without a long tender cycle.
Because we are the supplier, we can offer direct pricing, technical drawing review, and after shipment support. You do not need to go through layers of traders.
Typical industry applications include crude oil transfer in Nigeria, chemical solvents in Vietnam, dairy batching in New Zealand, and marine fuel oil measurement for vessels operating from Singapore.
Do not send a blank inquiry. The fastest path is to send process data in one message. If you only write price for a Coriolis flow me
What Data We Need for a Quotation
Send us these six items. Pressure (bar), temperature (°C), pipe size (DN), flow range (kg/h), fluid name and density, and viscosity at operating temperature. Add the ambient area classification if known, such as ATEX Zone 1 or Zone 2.
Most engineers skip this part and send a flow rate only. Then the quote gets delayed by viscosity or pressure questions.
We reply with a model, connection type, wetted material, transmitter details, power supply, output, accuracy, and price range. Most full requests from existing customers get a same day or next day answer.
For distributors, send the same data plus the end user location and the target commercial deadline. We can prepare a quote package with drawings and datasheets for your customer.
Accuracy, Pressure Ratings, and Hazardous Areas
A Coriolis mass flow meter from Silver Instruments typically delivers mass flow accuracy from ±0.1 to ±0.2 percent of rate for liquids. Gas accuracy is slightly wider. We do not quote one accuracy for every application because installation, flow profile, and zero conditions affect the result.
Process connections range from sanitary clamp and threaded on small diameters to flanged ANSI or DIN on DN50 and larger. Pressure ratings can be selected from PN16 to PN100 or higher depending on the body and process connection.
For hazardous areas, we supply ATEX Zone 1 and Zone 2 certified meters. We also handle IECEx requirements for countries that follow that scheme.
Temperature limits depend on the transmitter mounting. Integral mount transmitters are limited by the electronics temperature. Remote mounts allow higher process temperatures, often to 150 °C or 200 °C with special design.
Frequently Asked Questions
What is the smallest Coriolis mass flow meter size you offer?
We offer DN15 as the smallest standard size. It covers low flow dosing and pilot plant service. The exact flow range depends on the fluid density and required turndown.
Can Silver Instruments supply meters for ATEX Zone 1 service?
Yes. We supply ATEX Zone 1 and Zone 2 certified Coriolis meters. Let us know the area classification when you send the fluid data.
How fast can you send a quotation?
For complete process data, we usually reply within 24 hours. Complex applications with many variables may take 48 hours. Blank price requests take longer because we have to ask for the missing data.
Do you support viscous fluids like heavy fuel oil or molasses?
Yes. We size standard Coriolis meters for viscosities up to 1000 cP. Higher viscosity cases are evaluated against line pressure and pressure drop. Tell us the viscosity at operating temperature, not just at room temperature.
What information do you need for direct fluid sizing?
We need pressure in bar, temperature in °C, pipe size in DN, flow range in kg/h, fluid name and density, and viscosity. If the site has hazardous area requirements, add that too.
Contact Silver Automation Instruments
Send your pressure (bar), temperature (°C), pipe size (DN), and flow range to our flow engineering team. We will reply with a direct Coriolis mass flow meter model and price range.
